Booking 2.0.0 - Use Case 5 Confirm Booking Request - Sequence Model

Header Image

DCSA Repository / Interface Standards / Interface Standard Booking 2.0.0 and Bill of Lading 3.0.0 / Booking 2.0.0 - Use Cases - Sequence Model / Booking 2.0.0 - Use Case 5 Confirm Booking Request - Sequence Model

Project:
Booking 2.0.0 - Use Case 5 Confirm Booking Request - Sequence Model : Interaction diagram
Created: 11/14/2024 4:45:16 PM
Modified: 1/8/2025 11:30:19 AM
Project:
Advanced:
This diagram shows the response of the Carrier Internal System when the Carrier confirms the Booking.<br/>Note: This sequence is being followed by a Notification Sequence.<br/><br/><br/>
